HRM220 Series Hydraulic Reach Mower Package

SKU: HRM-HRM220-C100
Regular price $12,500.00 Inc. GST
Model Number

Multiple Delivery Options
Reliable Customer Support
Quality You Can Trust
CE Certification Standards

BUY ONLINE AND RECEIVE A FREE SET OF Y-BLADES

HRM220 Hydraulic Reach Mower Hedge Cutter for 30-100HP Tractors, PTO Shaft- Powered Cloveragri

The HRM220 Series Hydraulic Reach Mower is an ideal choice for agricultural land-clearing. Its compact arm allows for cutting grass and shrubs flush to the wheel without obstruction. It comes with a powerful Casappa hydraulic pump as standard, and includes 3 x cutting attachments  The HRM220 Hydraulic Reach Mower is a versatile and reliable cutting mower.

Included Cutting Attachments :

  • S340  Saw Attachment
  • T175 Hedge Cutter Attachment
  • Flail Mower Attachment



OVERVIEW

The HRM220 Hydraulic Reach Mower is a specialised cutter designed to excel in a range of applications, from clearing highway medians to initial land clearing for various projects, including housing developments, parks, and recreational areas. Its versatility extends to semi-professional use, where it proves ideal for pruning roadside hedges, maintaining traffic island greenery, and various other tasks including parks, gardens, Vineyards, and Orchards.

Powered by tractors PTO, the Hydraulic Reach Mower is compatible with a broad spectrum of 30-100HP compact tractors, such as Kubota, John Deere 2-3, Ford, McCormick, Iseki, Yanmar, Lamborghini, and Massey Ferguson ensuring accessibility and convenience for different tractor owners.

Minimum weight of the tractor: 1200kg

PTO shaft supplied with the machine.

BENEFITS & FEATURES

  • Hydraulic vale : Hydrocontrol ( Italian )
  • Double hydraulic pump: Casappa ( Italian ) allows to move together the arm and the mower.
  • Hydraulic motor (mower): Casappa ( Italian )
  • Casappa main pump for attachment motor : 43 L/min ( 2300 psi )
  • Casappa auxiliary pump for boom cylinders : 8 L/min ( 2300 psi )
  • 100% hydraulically operated arm to accommodate for any kind of gradient of terrain.
  • If the tractor is on slope the arm will steady itself to reduce downtime.
  • 55 litres oil tank - ISO 46 Hydraulic oil.
  • Adjustable roller on the Flail Mower Attachment.
  • Approx. 55L oil capacity ( ISO 46 Hydraulic Oil )

 Mower  Attachment Specifications:

  • 1230mm overall length
  • 330mm overall height
  • 530mm overall width
  • 1000mm cutting width
  • Motor speed : 2000 rpm
  • 40 x Y - blades
  • Weight : 88 kg
  • Hydraulic flow rate: min. 40 - 50 L/min.
  • Protected motor and Hydraulic connectons
  • Rear adjustable roller
  • Front and rear rubber flap
  • Direct drive
  • Pressure relief and anti-cavitation valve
  • 3 way flow control valve - pressure compensated

S340 Saw Attachment Specifications:

  • Saw blades: qty. 3
  • Saw blade diameter: Ø 400 mm
  • Saw drive: hydraulic
  • Hydraulic flow rate: min. 40 - 50 L/min.
  • Operating pressure: 2300 psi
  • Required hydraulic connection: 1x double acting.
  • Saw blade drive: V-belt
  • Saw blade thickness: 3 mm
  • Saw teeth: 72 teeth per saw blade
  • Effective cutting width: 900 mm
  • Branch diameter (max.): 100 mm
  • Operating speed: 2 - 7 km/h
  • Weight: approx. 55 kg



T175 Hedge Cutter Attachment Specifications

CHARACTERISTIC UNITS METRIC
Working width 1800.0 mm
Overall width 1880.0 mm
Weight 70.0 kg
Maximum cutting diameter 20 -30mm
Number of Blades 23
Min./Max. Relief Pressure 2300 psi
Min./Max. Flow 40 - 50 L/min
Packing sizes 1880x600x300 mm







Hrm220 series hydraulic reach dimensions diagram



MODEL SPECIFICATIONS

Mod. α β γ A B C
cm Min. Max. Kg L RPM ° ° ° cm cm cm
HRM220-C60 60 25 40 800 55 24 1000 176 116 123 250 310 320
HRM220-C80 80 25 40 800 55 32 1000 176 116 123 270 330 320
HRM220-C100 100 25 40 900 55 40 1000 176 116 123 290 350 320
PRODUCT DIMENSIONS DIAGRAM
