VCDH Series Bidirectional Mulcher Heavy Duty Plus

Cloveragri VCDH Series Bidirectional Heavy Duty Mulcher Plus, 1000 RPM, Hydraulic side shift, Pto shaft CE included.

The VCDH Bidirectional Heavy Duty Mulcher Plus is a specialised implement designed for professional green maintenance tasks, specifically suitable for tractors equipped with both rear and front P.T.O. Its meticulous attention to detail, including a helical arrangement of cutting hammer blades, balanced rotor, encased frame structure, hydraulic side shift movement, and 5 x belt transmission, sets it apart as a top choice for achieving exceptional results in landscaping and maintenance projects.

OVERVIEW

The VCDH Bidirectional Heavy Duty Mulcher Plus stands out as a versatile and highly efficient machine tailored to the needs of green maintenance professionals. Specifically designed for tractors equipped with both rear and front P.T.O., this mulcher demonstrates its professionalism through meticulous attention to detail, setting it apart from traditional shredders.

One of its key features is the helical arrangement of cutting hammer blades on the rotor, ensuring an even workload distribution and remarkable balance, resulting in significant vibration reduction during operation. Moreover, the counterweights on the balancing discs, as opposed to being welded to the rotor, contribute to its efficient performance. The frame of the VCDH series showcases an encased structure with two separate beams, enhancing the optimal balance between weight and rigidity. Additional features like 16mm skids, hydraulic side shift movement, a roller with bolted flanges, and a 5 x belt transmission with a belt tightener all contribute to positioning the VCDH series as a top choice among professional shredders.

Whether you're maintaining green spaces, parks, or any landscaping projects, the VCDH Bidirectional Mulcher Heavy Duty Plus provides the reliability and precision needed to achieve exceptional results in your professional maintenance endeavours.

BENEFITS & FEATURES

• Multitasking Capability: Designed for professional green maintenance tasks, suitable for tractors with rear and front P.T.O

• 5mm Deck Thickness

• 10mm Side Wall Thickness

• 16mm Skids

• 194mm Blade Carrier Diameter

• 1110kg weight VCDH280

• 1180kg weight VCDH300

• 5 x B Section Drive Belts

• 8 to 10cm cutting diameter

• Suited to tractors 85 to 130HP

• Helical Cutting Tool Arrangement: Ensures even distribution of workload and balanced operation, reducing vibration.

• Counterweights: Distributed on balancing discs, enhancing stability and performance.

• Encased Frame Structure: Features two separate beams in the front and upper sections, optimising the weight-to-rigidity ratio.

• Self Cleaning rear roller and side skids.

• Hydraulic Movement: Provides precise control over the mulcher's positioning and operation.

• Bolted Flanges on Roller: Ensures secure attachment and ease of maintenance.

• Belt Transmission: Includes a belt tightener for efficient power transfer.

• Professional Grade: Tailored for commercial landscaping and maintenance projects, meeting the demands of green maintenance professionals.

• PTO Shaft included.

• Warranty : 2 years

MODEL SPECIFICATIONS

MODEL SPECIFICATIONS

Mod.									A	B	C
	CM	Min.	Max.	CM	n°	n°	n°	RPM	CM	CM	CM
VCDH260	250	85	130	128 122 58 192	22	N/A	5	1000	269	117	118
VCDH280	280	95	130	128 146 58 216	24	N/A	5	1000	288	117	118
VCDH300	300	100	130	153 156 82 229	26	N/A	5	1000	308	117	118

PRODUCT DIMENSIONS DIAGRAM
