VD Series Bidirectional Mulcher Heavy Duty
Couldn't load pickup availability
VD Bidirectional Mulcher, Hydraulic Movement, Three-Point Hitch, Front/Rear Tractor Attachment, 540 RPM - Cloveragri
The VD Series Bidirectional Mulcher is a versatile agricultural implement that can be attached to the front or rear of a tractor, providing flexibility in equipment configurations. Its robust frame, hydraulic movement, and reversible three-point hitch make it suitable for a wide range of tasks, including grass shredding, vineyard and orchard maintenance, and efficient cornstalk processing, enhancing land management capabilities for agricultural professionals.
OVERVIEW
The VD Series Bidirectional Mulcher is a versatile and highly adaptable machine designed to meet the diverse needs of agricultural and land maintenance tasks. Its standout feature is the reversibility of the three-point hitch, enabling usage at both the front and rear of the tractor. This unique capability not only allows for flexible configurations but also opens up opportunities to attach additional equipment to the tractor's opposite end when the mulcher is in use.
With a robust frame and hydraulic movement, the VD Series ensures optimal performance across various operational scenarios, making it an excellent choice for tasks such as shredding grass, clearing twigs in vineyards or orchards, and effectively processing cornstalks. Whether you're tending to agricultural fields or maintaining orchards, this mulcher's versatility and reliability shine through in enhancing your land management capabilities.
BENEFITS & FEATURES
- Reversible use ( Front or rear of tractor ) 540 + 540 r/min
- Double case.
- Hydraulic side shift.
- 4 high resistance toothed belts, and external belt tensioner.
- 152.0 mm adjustable roller unit and skids.
- Electronically balanced rotor.
- Adjustable roller unit and side skids.
- Pto shaft CE included.
| CHARACTERISTIC | VD220 | VD180 |
|---|---|---|
| Working width | 2200mm | 1800mm |
| Overall width | 2350mm | 1900mm |
| Min / Max cutting height | 5.0 - 55.0 mm | 5.0 - 55mm |
| Weight | 570 kg | 520 kg |
| Overall height | 1050mm | 1050mm |
| Tractor Power Range | 70 - 100 Hp | 60 - 80 Hp |
| 3 point linkage | Cat. 2 | Cat. 2 |
| Position of the gearbox | 800.0 mm from left side / 1400.0 mm from right side | 800.0 mm from left side / 1000.0 mm from right side |
| Hood height | 500mm | 500mm |
| Hydraulic Pipes (2) | 2500mm / connections 1.2" AGRI, WP-400 bar | 2500mm / connections 1.2" AGRI, WP-400 bar |
| Spacing between the 2 lower points | 740 - 890mm | 740 - 890mm |
| Number of Hammers | 20 | 18 |
| Maximum cutting diameter | 40 - 50mm | 40 - 50mm |
| Overall length | 1030mm | 1030mm |
| Distance between pto attachment and ground | 550.0 mm | 550mm |
| Main hood thickness | 4.5mm | 4.5mm |
| Sides thickness | 8mm | 8mm |
| Skid plates thickness | 8mm | 8mm |
| Transmission: Drive method | V-Belts | V-Belts |
| Gearbox | 2 years warranty | 2 Years warranty |
| Transmission: PTO | 540 r/min | 540 r/min |
| Transmission: Rotation of gearbox | Right side | Right side |
| Transmission: Free wheel | YES | YES |
| Transmission: RPM Rotor speed | 2140 rpm | 2140 rpm |
| Gearbox Oil | 80W-90 |
80W-90 |
| V-Belts quantity | 4 | 4 |
| V-Belts size | 17x1270 | 17x1270 |
| Rotor: diameter | 152mm | 152mm |
| Rotor: bearings type and size | 40x90mm - 1309 | 40x90mm - 1309 |
| Rotor: balancing | Electronic | Electronic |
| Rotor: sheet thickness | 8mm | 8mm |
| Hammers: Weight | 1.1kg | 1.1kg |
| Hammer: øhole | 16mm | 16mm |
| Hammer: base width | 140mm | 140mm |
| Hammer: top width | 40mm | 40mm |
| Hammer: Diagonal | 97mm | 97mm |
| Rear roller: diameter | 152mm | 152mm |
| Rear roller: sheet thickness | 6mm | 6mm |
| Rear roller: bearings type and size | 90x40mm - 6308 | 90x40mm - 6308 |
| Pto shaft | Included |
Included |
| Hood length | 1000mm | 1000mm |
| Effective Displacement | 400mm (Hydraulic) | 400mm (Hydraulic) |
| Packing Dimmensions | 2450x945x810mm | 2050x945x810mm |
MODEL SPECIFICATIONS
|
Model |
Deck thickness mm |
Side thickness mm |
Skid thickness mm |
Number of belts |
Number of hammers |
Blade carrier diameter mm |
Weight kg |
Packing Dimensions |
|
VD180 |
4.5 |
8 |
8 |
4 |
18 |
152 |
520 |
2050×945×810 |
|
VD220 |
4.5 |
8 |
8 |
4 |
20 |
152 |
570 |
2450×945×810 |
PRODUCT DIMENSIONS DIAGRAM
